Standard Features

Key Features
• Storage interface (SAS/SATA)
o 8 SAS lanes across 2 x4 internal Mini-SAS ports
o 12Gb/s SAS, 6Gb/s SATA technology
o Mix-and-match SAS and SATA drives to the same controller
o Support for SAS tape drives
• PCI Express 3.0 x8 link
• RAID 0, 1, 5, 10
• Mixed Mode (RAID logic drives and HBA physical drives simultaneously)
• Windows Storage Spaces Direct validated
• VMware Virtual SAN certified
• Legacy and UEFI boot operation
• UEFI System Utilities (storage configuration)
• Up to 238 physical drives
• Up to 64 logical drives
• HPE Smart Array SR Secure Encryption (optional license)
• HPE SSD Smart Path
• Rapid Parity Initialization (RPI)
• Rapid rebuild
• Drive Sanitize
• Performance Optimization-Degraded Reads and Read Coalescing
• Power efficiency
• Seamless upgrades from HPE Smart Array Software RAID
• Seamless upgrades to HPE Smart Array P-class Controllers

Ports
• Internal: 8 SAS/SATA lanes across 2 x4 internal Mini-SAS ports

Form Factor
• PCIe Plug-in Controller (occupies a PCIe expansion slot)

Performance
• 12Gb/s SAS (1200 MB/s theoretical bandwidth per physical lane)
• 6Gb/s SATA (600 MB/s theoretical bandwidth per physical lane)
• PCI Express 3.0 x8 link width

Fault Prevention
The following features offer detection of possible failures before they occur:
• Predictive drive failure detects possible drive failure before it occurs, allowing replacement of the component before failure occurs.
• Background surface scan checks drives during inactive periods and automatically remaps bad sectors, ensuring data integrity.
• HPE SmartSSD Wear Gauge reports the amount of lifetime remaining on your SSDs.

Fault Recovery
Minimizes downtime, reconstructs data, and facilitates a quick recovery from drive failure • Recovery ROM: This feature protects the user from a firmware image corruption by storing a redundant copy of the firmware image. If the active firmware image becomes corrupt, the controller will use the redundant firmware image and continue operating.
• On-Line Spares: There is no limit to the number of spare drives that can be installed prior to drive failure. If a failure occurs, recovery begins with an On-Line Spare and data is reconstructed automatically.
• DRAM ECC detects and corrects data bit errors
