Certification
CE ROHS 3C EAC NOM IC

Humidity
Operating Environment:10% ~ 90% RH Non-condensing
Storage Environment:5% ~ 90% RH Non-condensing

Temperature
Operating Environment:0℃ ~ 40℃
Storage Environment:-40�C~70�C

Dimension
127.4mm*90.5mm*26mm

DHCP Server
Support

System Tool
Network Time, Sys Upgrade, Backup/Restore, Factory Default, Login Password, Sys Logs, Restart.

Safety
WPA Algorithm: AES, TKIP, TKIP&AES
Wireless Access Control: MAC Address Filtering

Antenna
3x5dBi external undetachable antennas

Power Consumption
1.9W(no load)~3.3W(full-load)

Power Supply
DC 9V 600mA

Button
1*WPS/RESET

LED
SYS, WiFi, LAN(1-3), WAN, T, WPS

Frequency
2.4GHz

Interface
1*10/100M auto-negotiation WAN port
3*10/100M auto-negotiation LAN ports

Standard&Protocol
IEEE802.11/b/g/n

Speed
300Mbps over 2.4GHz band
