Mechanical
Dimensions: 200 x 248 x 44 mm (7.9 x 9.8 x 1.7")
Weight: 2.4 kg (5.29 lb)
Enclosure Material: Polycarbonate
Mount Material: Polycarbonate
Hardware
Total Non-Blocking Throughput: 40 Gbps
Switching Capacity: 80 Gbps
Forwarding Rate: 59.52 Mpps
Max. Power Consumption: 120W
Power Method: (1) 100-240VAC, 2A Max., 50/60 Hz, Universal Input
Power Supply: AC/DC, Internal, 150W
Management Interface: Ethernet In-Band
Networking Interfaces: (8) 1/2.5 Gbps RJ45 Ethernet
SFP+ Interfaces: (2) 1/10 Gbps SFP+
PoE Interfaces: (8) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE+ Wattage per Port by PSE: 32W
Voltage Range 802.3af Mode: 44 to 57V
Voltage Range 802.3at Mode: 50 to 57V
Services: SMB Layer 3* PoE Gigabit Ethernet Switch
LCM Display:
- (1) 1.3" Touchscreen
- Bootup Animation: Bootup in Progress
- Firmware Upgrade Icon: Firmware Upgrading
- Steady White: Factory Defaults, Awaiting Adoption
- Steady Blue: Device is Adopted
ESD/EMP Protection: Air: ± 16kV, Contact: ± 12kV
Operating Temperature: -5 to 40° C (23 to 104° F)
Operating Humidity: 10 - 90% Noncondensing
Certifications: CE, FCC, IC
