Network Parameters
Port Number: 24 × gigabit RJ45 ports
Port Type: RJ45 port, full duplex, MDI/MDI-X adaptive
Working Mode: Standard mode (default)
Standard: IEEE 802.3, IEEE 802.3u, IEEE 802.3x, and IEEE 802.3ab
Forwarding Mode: Store-and-forward switching
MAC Address Table: 8 K
Internal Cache: 2 Mbits
Switching Capacity: 48 Gbps
Packet Forwarding Rate: 35.712 Mpps

Software Function
Device Maintenance: Support remote upgrade, recovering default parameters, viewing logs, configuring basic network parameters.

General
Shell: Metal material, IP40
Net Weight: 1.62 kg (3.57 lb)
Gross Weight: 2.545 kg (5.61 lb)
Dimension (W × H × D): 335 mm × 44.5 mm × 175.8 mm (13.19” × 1.75” × 6.92”)
Operating Temperature: -10°C to 55°C (14°F to 131°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Operating Humidity: 5% to 95% (no condensation)
Relative Humidity: 5% to 95% (no condensation)
Power Consumption In Idle: 5 W
Power Supply: 220 VAC, 50/60 Hz, Max. 0.7 A
Max. Power Consumption: 13 W

Approval
EMC: FCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 20)
Safety: UL (UL 62368-1); CB/RCM (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2030)
Chemistry: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
