Optical
Optical sensor: Linear image2500 pixels
Light source: Visible Red light 632nm LED
Resolution: 4mil/0.1mm@PCS90%, Code39
Depth of Field: 200mm(20mil)/0,5mm. PCS90%
Width of Field 40mm@Contact, 10mil/0.25mm, PCS90%
Processor type: 32 bits
Scan Rate: 100 scans per second ±10%
Pcs: 45%

Electrical
Voltage: +5V±5%
Scanning currents: 242mA
Standby currents: 58mA
Power on Consumption: 250mA

Environment
Operating temperature: 0°C to 50°C / 32°F to 122°F
Storage temperature: -20°C to 70°C / -4°F to 158°F
Light level: 10,000 Lux. Max
Operating humidity: 20%~ 95% non-condensing
Storage humidity: 20% ~ 95% non-condensing
Shock resistance: 1.5m drops

Physical
Weight: LN1100 scanner only (90g), Cable- USB (60g)
Dimensions: 168mm(L)x55mm(W)x65mm(H)
Housing Material: ABS plastic
Cable Lenght: 1500mm

SUPPORTED BARCODE
(Default Enable) All UPC/EAN/JAN;
Code 39;
Code 128;
CODABAR/NW7;
Interleave 25 (Readable) All UPC/EAN/JAN;
EAN 128 Code;
Code 39;
Code 39 Full ASCII;
Code32/Italian Pharmacy;
Code 128;
CODABAR/NW7;
Interleave 25;
Industrial 25;
MSI/PLESSEY;
Telepen;
Code 93;
China Postage;
GS1 DataBar
