Standard&Protocol
IEEE 802.3、IEEE 802.3u、IEEE 802.3x

Transmission Media
100BASE-TX: Cat.5, Cat.5e or Above（≤100m）UTP/STP

Interface
5*10/100Mbps auto-negotiation RJ45 ports, auto MDI/MDIX

LED
1*power LED，5*10/100Mbps Link/Act LEDs

Dimension
100mm�64mm�25mm(W*D*H)

Forwarding Mode
Store-and-Forward

MAC Address Table
1K

Forwarding Rate
10BASE-T：14881pps/port
100BASE-TX：148810pps/port

Backbound Bandwidth
1.0Gbps

Power Input
100~240V AC，50/60Hz

Power Output
5V DC，0.6A

Temperature
Operation Temperature:-10°C~45°C
Storage Temperature:-40°C~70°C

Humidity
Operation Humidity:10%~90% RH（non-condensing）
Storage Humidity 5%~90% RH（non-condensing）
