Dimensions: 122.5 x 107.1 x 28.0 mm (4.82 x 4.22 x 1.10")
Weight: 230 g (8.11 oz)
Networking Interfaces: (5) 10/100/1000 Mbps RJ45 Ports
Management Interface: Ethernet In-Band
PoE Out (Ports 2-5): 802.3at (Pins 1, 2+; 3, 6-)
Max Power Consumption (Excluding PoE Output): 5W
Max PoE Wattage Per Port: 25W
Total PoE Power Budget
Powered by 802.3af: 8W
Powered by 802.3at: 20W
Powered by 802.3bt: 46W
Powered by PoE Adapter (Enabled in Controller): 46W
Voltage Range
802.3af: 44 - 57V
802.3at/bt: 50 - 57V
LEDs
System: Status
RJ45 Data Ports: PoE; Link/Speed/Activity
ESD/EMP Protection: ± 16kV Air, ± 16kV Contact
Certifications: CE, FCC, IC
