GENERALI
- 802.11ac fino a 867Mbps in 5GHz
- Antenna direttiva ad alto guadagno 23dBi ideale per collegamenti a lunga distanza
- Struttura robusta con assemblaggio rapido a incastro per la massima stabilità anche in condizioni di forte vento
- Certificazione IP65 contro le intemperie, protezione da scariche elettriche 15 kV ESD e 6 kV
- Gestione centralizzata con software gratuito Pharos Control
- Supporto Passive PoE per installazione flessibile.
CARATTERISTICHE HARDWARE
Processore: Qualcomm 750MHz CPU, MIPS 74Kc
Memoria: 128 MB DDR2 RAM, 16 MB Flash
Interfaccia:
- 1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE)
- 1 Reset Button
Alimentazione:
- Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
- Voltage range: 16-27V DC
Dimensioni ( L x P x A ): 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
Guadagno antenna: 23 dBi
Ampiezza del diagramma di emissione: 9° (Azimuth)/7° (Elevation)
Sicurezza:
- 15 KV ESD Protection
- 6 KV Lightning Protection
Enclosure:
- Material: Outdoor PC stabilized plastic
- Weatherproof: IP65 water and dust proof design
CARATTERISTICHE WIRELESS
Standard wireless: IEEE 802.11a/n/ac
Velocità wireless:
- Up to 867 Mbps (80 MHz, Dynamic)
- Up to 400 Mbps (40 MHz, Dynamic)
- Up to 173.4 Mbps (20 MHz, Dynamic)
Frequenza: 5.15–5.85 GHz
Potenza di trasmissione: Max. 27 dBm (Adjustable power by 1dBm)
CARATTERISTICHE SOFTWARE
Configurazione di rete:
WAN: Static/ Dynamic/ PPPoE
LAN: Static/ Dynamic/ DHCP
Forwarding: ALG/ UPnP/ Virtual Server/ Port Trigger
Security: SPI Firewall/ Ping Forbidden/ DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding
Configurazioni wireless:
Selectable Channel Width: 20/40/80MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/ Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
SSID Broadcast Enable/ Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/ RTS Threshold/ Fragmentation Threshold/ DTIM Interval/ AP Isolation/ Short GI/ Wi-Fi Multimedia
Long Range PtP
Gestione:
Discovery and Remote Management via Pharos Control application
HTTP/ HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
Tool di sistema:
Indicators:Signal Strength/ Noise/ Transmit CCQ/ CPU/ Memory
Monitors: Throughput/ Stations/ Interfaces/ ARP/ Routes/ WAN/ DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Antenna Alignment
Ottimizzazioni di sistema: Optimized IGMP Snooping / Proxy for multicast applications
CARATTERISTICHE ADATTATORE POE
Dimensioni ( L x P x A ): 85.8×43.9×29.7 mm
Interfacce:
1 AC Jack with Earth Ground
1× 10/100/1000 Mbps Shielded Ethernet Port (Power + Data)
1× 10/100/1000 Mbps Shielded Ethernet Port (Data)
Tasto: Remote Reset Button
Indicatori di carica LED: Green
Input: 100-240VAC, 50/60Hz
Output: 24VDC, 0.5A Max
+4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet)
Efficienza: >84.29%
Certificazioni: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
ALTRO
Certificazione: CE, FCC, RoHS, IP65, IC
Contenuto della confezione:
- Outdoor Wireless CPE
- 24V 0.5A Passive PoE Adapter
- Pole Mounting Kits
- AC Power Cord
- Installation Guide
Requisiti di sistema:
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Ambiente:
Operating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
