• Classy and simplistic front panel design
• USB 3.0 super speed port (internal)
• Top mounted PSU slot for best PSU compatibility
• Large tray cut-out for easy CPU cooler installation
• Supports all High-End VGAs including the HD7990
• Exposed 3.5” Slot for CardReaders
• Tool-free system for ODDs, card reader and HDDs
• VGA cooling vent with 120/140 mm fan support
• HDD cooling vent with 2x120mm fan support
• Supports up to 6 fans in total (1 pre-installed)

Model

FOR-500-KKN1



Available Color

Black



Materials

Steel body, plastic



Dimensions (W x H x D)

190 x 426 x 491.5mm



Net Weight

5.23 kg



M/B Type

microATX, ATX



5.25" Drive Bays 2 (exposed)

3.5" Drive Bays 8 (1 exposed, 7 hidden)

2.5" Drive Bays 1 (hidden)



I/O Panel

USB 3.0 x 1 (int.), USB 2.0 x 2, Mic x1, Audio x 1 (supports AC97 / HD Audio)



Expansion Slots

7



Cooling System

Front: 140mm fan x 1 (optional), or 120mm fan x 2 (optional)

Rear: 120mm black fan x 1 (installed)

Side (left): 120/140mm fan x 1 (optional)

Side (right): 120mm fan x 2 (optional)



Power Supply Type

Standard ATX PS2 / EPS 12V



Maximum Compatibility

VGA card length:

320mm with HDD cage)



CPU cooler height:

163.9mm
